SS D

NP ELECTRONIC

Supply Voltage: 220V AC or 24V AC/DC
Operation Frequency: 50/60 Hz
Off Time Range: 10 - 300 msec. (adjustable)
Star Relay OnTime Range: 0,1 - 30 sec. (adjustable)
Operation Temperature: -5....+55°C
Protection Class: IP 20
Sensitivity: ±%2
Relay Contact: 7A - 250V AC (NC+NO)
Dimensions (mm): 23x82x75
Net Weight: 90 GR
