SVP 05F

Supply Voltage: 3x380V AC
Operation Frequency: 50/60 Hz
Voltage Control Range: Vdn: 310V - 370V (ayarlanabilir) (%2,5U-%15U) Vup: 390V - 430V (ayarlanabilir) (%2,5U-%10U)
Off Delay Time: 0,1 - 10 sec. (adjustable)
On Delay Time: 1 sec. (sabit)
Operation Temperature: -5....+55°C
Protection Class: IP 20
Sensitivity: ±%1
Relay Contact: 7A - 250V AC (NC+NO)
Dimensions (mm): 23x82x75 (SVP-05F) 30x60x90 (RVP-05F)
Net Weight: 140 GR
